Type: B

Japan Power Cords, JIS C 8303 Plug, Type B, 3 poles, PSE Certified

Japan Power Cords, 7A, 12A, 15A 125V, Type B Plug. The Japan AC Cords according to JIS C 8303 Standards with PSE certification. Non-Rewirable Plug 2 poles with Earthing Contact Moulded with Flexible cords. This Japan Three prong Power Cords match cable for general applications include Flexible cables with thermoplastic PVC Insulation and Flexible cables with crosslinked elastomeric Rubber Insulation in Japan market. Our Japan Power Cords Products are fully molded with a low profile ergonomic design and RoHS and Reach compliant.

Plug Type :B

Approvels :PSE Certified

Electrical Rating :7A, 12A, 15A

Voltage :125V

Plug / Connector Standards :Japan JIS C 8303

Japan PSE 3 pins JIS C 8303 plug, Japan Power Supply Cords with PSE Certified List.
Built to Japan JIS C 8303 standards.
Rated up to 7A, 12A, 15A 125V.

Categories: Japan PSE Power Cords

Japan Power Cords, JIS C 8303 Plug, Type B, 3 poles, PSE Certified Product Description


Plug / Connector Standard:	Japan JIS C 8303
Maximum Current rating:	7A, 12A, 15A
Maximum Voltage:	125V
Number of Poles and Wires:	3 poles, 3 wires
Copper Conductor Material:	Oxygen free Copper (OFCU)
Outer Jacket Material:	PVC, Rubber, Halogen-Free, Textile braid
Blade Material:	Nickel Coated Brass
Flamability Rating:	UL 94V-0
Color	Black / White are standards, but any color available customized
Environmental Certifications:	RoHS, Reach, PAHs
Testing:	Hi-Pot (Dielectric Withstanding Voltage), Polarity (pinout) and Continuity
Country of Origin:	Made In China
Packing:	Standard Export Carton

Japan Power Cords, JIS C 8303 Plug, Type B, 3 poles, PSE Certified Available Cord / Cables Wire Styles

Gauge/ # Conductors	Cord Type
3x0.5mm², 3x0.75mm², 3x1.25mm², 3x2.0mm²	VCT, VCTF, HVCTF
3x0.5mm², 3x0.75mm², 3x1.25mm², 3x2.0mm²	2PNCT

More pictures of Power Cords for reference:

Japan Power Cords, JIS C 8303 Plug, Type B, 3 poles, PSE Certified

Power Cords Terminals Processing Available Opposite End

We have the ability to customize the opposite end of various power cords, stripping cables,
including any terminals, Strain Relief customization and design.
To match the personalization request in field of power cord connectors of each customer.
